Product Information

Berridge Manufacturing Company offers premium, fluoropolymer-coated Galvalume® flat sheet material in 24 & 22 Gauge painted with full-strength Kynar 500® or Hylar 5000® resins. Kynar 500® or Hylar 5000® afford maximum exterior durability due to outstanding resistance to ultraviolet radiation. (See chart of Berridge’s SRI Values.) Full-strength Kynar 500® or Hylar 5000® color finishes carry a 20-year guarantee against cracking, peeling, and fading. These are the highest-quality exterior finishes available! All Berridge colors are entirely processed and finished on Berridge’s continuous coil coating line in San Antonio, Texas, and are proprietary finishes of Berridge Manufacturing Company. They are available on all Berridge products and in sheet and coil form. For a preview of all of Berridge’s colors, view our color chart. Custom colors are also available.

CUSTOM TRIM PRICING

Berridge custom trim is priced by the total stretch of flat material rounded to the nearest half-inch. Trim pieces are available in 10′ lengths. Please get in touch with your Berridge salesperson for a price estimate: (800) 669-0009

Materials

  • Standard material is 24-Gauge, Galvalume®
  • Optional 22-Gauge Galvalume®
  • Unfinished material is Acyrlic Coated Galvalume®
  • Galvalume® coating is an alloy composed of 55% aluminum and approx. 45% zinc by weight applied according to ASTM A792
  • Grade 40, 40 ksi steel

Specifications

  • Customer must provide trim drawings to include: shape, dimensions, angles, open or closed hems, and the finish side.

Installation

  • Strippable plastic film is applied over all prefinished coils. This film must not be exposed to sun or moisture and must be removed prior to material installation.
  • Keep all materials stored in a well ventilated, dry area and out of sunlight.

Technical

Add this item to the download cart, so you can retrieve it as part of a ZIP file.
Download this item directly to your computer.

Downloads

Add this item to the download cart, so you can retrieve it as part of a ZIP file.
Download this item directly to your computer.
